You can also still drag and reposition the aircraft even if it is moving.
TIMS AIR NAVIGATION SIMULATOR SIMULATOR
You must click on any blank portion of the simulator to allow the browser to transfer keyboard commands to it. In addition, if clicking outside the simulator (like clicking on the browser scroll bar, text or any other area outside) the browser may stop sending the keyboard commands to the simulator. IMPORTANT KEYBOARD CONTROL NOTE: The simulator start button must be pressed and the aircraft rotating-arround-the-globe icon must be moving for the keyboard commands to work. The following are the keys that control the aircraft: You can use the keyboard to control the movement of the aircraft. Knobs are set the same way as the heading of the aircraft (as described above), except that instead of placing the mouse on the aircraft symbol, the mouse is placed on the knob. Release the Shift button to hide the blue line. Clicking the mouse button will change the aircraft heading to the current direction of the blue line. While holding the Shift key down and moving the mouse cursor around the map, the arrow radiating from the aircraft will follow the mouse constantly showing the direction from the aircraft. Holding Shift key down and moving the cursor near the aircraft center will display a blue arrow extending from the center of the aircraft with the current direction of the arrow from the aircraft in degrees displayed on the line. Changing the value in the edit box to any value from 1 to 360 will change the aircraft heading to that heading.Ģ. Double clicking on the aircraft will cause a small window near the aircraft to open with the current heading in the edit box. If Heading Up is selected, aircraft heading changes can be set by positioning the cursor close to the navigational facility on the horizontal panel then clicking the button when a "-" or "+" appears.Īdditionally there are two new ways to set the aircraft's heading:ġ. If North Up is selected aircraft heading changes can be set by positioning the cursor close to the aircraft on the horizontal panel then clicking the button when a "-" or "+" appears. Drag aircraft on horizontal or vertical panels to change the aircraft's position in relation to the facility. (F lash Required - Duration: 13 minutes - Size: 64 MB - broadband internet connection highly recommended )Ĭondensed Instructions: ( printable version click here) VOR Simulator Holding Pattern Demonstration
TIMS AIR NAVIGATION SIMULATOR MOVIE
If you have a broadband connection watch the VOR Simulator demonstration movie by clicking on the link below The VOR (VHF Omnidirectional Range) Simulator was designed to demonstrate the approximate indication that a VOR would display with varying positions of an aircraft in relation to certain navigational facilities.
